Vagrant VirtualBox Enable Nested Virtualization

Working with VirtualBox and Windows Subsystem for Linux 2 has often been a source of frustration.

When we use VirtualBox on Windows with WSL2 enabled, we have to use the hyper-v paravirtualization engine. Unfortunately, this engine doesn’t play well with Vagrant, limiting our options.

However, our experts have a solution! We can leverage nested virtualization in WSL2 to overcome this limitation. By running VirtualBox directly inside WSL2 without any paravirtualization constraints, we can unlock a new level of flexibility. The key is to set up a custom kernel for WSL2 with the right kernel modules. Let’s take a quick look at the process.

Building a Custom Kernel for WSL2

1. To begin with, make sure the following kernel configurations are in place:

   CONFIG_MODULES=y
CONFIG_MODULE_SIG=n
CONFIG_SECURITY_LOADPIN=n
CONFIG_SECURITY_LOCKDOWN_LSM=n
2. Then, manually disable the `config_module_sig` check to make sure the `module_sig_check` function always returns 0. We have to make this change in `kernel/module.c` at line 2786.
3. Now, it is time to build the kernel and install the modules to `/lib/modules`:

   sudo make -j $(nproc)
sudo make -j $(nproc) modules_install

Setting Up VirtualBox in WSL2

After the custom kernel is in place, the process becomes more straightforward:

1. Update `%userprofile%\.wslconfig` to use the new kernel image.
2. Then, install VirtualBox-6.1.

After the above steps, we have successfully sidestepped the paravirtualization limitations.

Vagrant Compatibility

We can make Vagrant work seamlessly with this setup with these additional steps:

1. To begin with, use a Vagrant branch that disables checks for WSL.
2. We can build Vagrant with the following instructions:


cd ~
git clone https://github.com/askalice/vagrant
cd vagrant
bundle install
bundle -- binstubs exec
export PATH="$(dirname ~/vagrant/exec)/exec:$PATH"

3. For parallel Vagrant installs against Windows, we have to add the following to our `.bashrc`:


export VAGRANT_WSL_NESTED_VIRTUALIZATION=true
export VAGRANT_HOME=~/.vagrant-wsl2
export VAGRANT_DOTFILE_PATH=.vagrant-wsl2


Running Virtual Machines with Nested Virtualization

If you want to run lab environments on a Mac using VirtualBox, follow these steps:

1. Download and install the latest version of VirtualBox for MacOS.
2. Then, install Vagrant.
3. Now, create a `Vagrantfile` in our desired directory with the following contents:

   Vagrant.configure("2") do |config|
config.vm.box = "ubuntu/trusty64"
# enable nested virtualization
config.vm.provider "virtualbox" do |vb|
vb.customize ['modifyvm', :id, '--nested-hw-virt', 'on']
end
end

4. Finally, launch the virtual machine with `vagrant up`.

Let us know in the comments if you run into any trouble with the above instructions.

[Need assistance with a different issue? Our team is available 24/7.]

Conclusion

In brief, our Support Experts introduced us to Vagrant VirtualBox & enablng nested Virtualization
